MULT-ISPLIT System outdoor unit 1-drive-4 R32 inverter M4OC-30CFN8

Outdoor for 2 ~ 4 zones

JM4OC-36CFN8

Cooling

(Standard conditions)

Capacity

Btu/h

Btu/h

32000（12000~32000)

kW

kW

9.38

Input

W

W

2877（837~2900)

Current

A

A

11.6（5.4~14.0)

EER

W/W

W/W

3.26

Rated Power Input

W

4000

Rated Current

A

16.5

Compressor

Model

KTM240D46UKT2

Type

ROTARY

Brand

GMCC

Capacity

W

4780/7600

Input

W

805/2045

Rated current(RLA)

A

4.15/9.30

Locked rotor Amp(LRA)

A

/

Thermal protector

/

Thermal protector position

NA

Capacitor

μF

/

Refrigerant oil/oil charge

ml

VG74 620

Outdoor fan motor

Model

ZKFN-80-8-3

Qty

1

Input

W

/

Capacitor

uF

/

Speed

r/min

850/550

Outdoor coil

a.Number of rows

2

b.Tube pitch(a)x row pitch(b)

mm

21x13.37

c.Fin spacing

mm

1.3

d.Fin type (code)

Hydrophilic aluminum

e.Tube outside dia.and type

mm

Φ7,Inner groove tube

f.Coil length x height x width

mm

910*609*13.37+890*609*13.37

g.Number of circuits

5

Outdoor air flow

m3/h

3000

Outdoor sound pressure level

dB(A)

55.5

Throttle type

EXV+Capillary

Outdoor unit

Dimension(W*D*H)

mm

890x342x673

Packing  (W*D*H)

mm

1030x438x750

Net/Gross weight

kg

45.1/48.7

Refrigerant

Type

R32

GWP

/

Charged quantity

kg

1.5

Design pressure

MPa

4.3/1.7

Refrigerant piping

Liquid side/ Gas side

mm(inch)

4x6.35mm(4x1/4in)/4x9.52mm(4x3/8in)

Max. length for all rooms

m

80

Max. length for one indoor unit

m

35

Max. height difference between indoor and outdoor unit

m

15

Max. height difference between indoor units

m

10

Room temperature

Outdoor(cooling/heating)

℃

-15～50
